Paper Slitting Machine

We feel proud to introduce ourselves as the well-known manufacturer and supplier of Paper Slitting Machine. The offered paper slitting machine is a unique fabrication for cutting the paper rolls in industrial applications. Our supplied paper slitting machine is highly acclaimed and appreciated by the clients, due to the quick slitting mechanism and durable construct.

Features:

• Equipped with rewinding shafts
• Swinging arms
• Adjusts pressure between the center drum and rewind reels

Other Details:

• Most versatile, model providing combination of duplex center cum surface rewind system
• Constantly flawless slit rolls by providing center driver drum to maintain.Fixed minimum distance between slitting and rewind point
• Constant line speed causes constant tension rolls
• Two Rewinding shafts carried on swinging arms are center driven through adjustable slipping clutch
• Counterbalance system to adjust the pressure between rewind reels and center drum
• Suitable for off caliper / slippery / stretchy material
• In a special case, rewinding shaft can be supplied with a provision of an individual.
• Different slip assembly for each slit reels
• Slitting methods as per customer requirement like: Scissor cut/crush cut (Circular knives)/ Razor blade slitting system

Technical Specifications :

• Web width : 400 to 3500 mm
• Min. slit width : 50 mm
• Dia. Of finished roll : 400 to 600 / 1000 mm (Optional)
• Operating speed : 3-15 HP at 415 V, 3 Phase, 50 cycles A.C. Supply

Optional Attachments:

• Auto tension control for unwind unit
• KMT Web edge guide system (Hydraulic / Digital ultrasonic)
• Pneumatic system for Arm / Clutch /Brake /Nip
• Air shaft for unwind station
• Digital line edge guide system Safety chucks Bow rollers
• Four motor synchronised drive
• Shaftless Unwinder
• Pneumatic Lifter etc

Layout of Accusplice - Duplex Surface Slitter & Rewinding Machine:

• Unwind Roll
• Auto Tension Control Brake Or Mechanical Brake
• Edge Guide Control Unwind Frame. Structure (movable) Or Fix Unwind Frame
• Pneumatic Or Line Sensor 5.Dancing Roller
• Nip Roller Set 7 Slitting Attachment
• Adjustable Pressure Roll
• Drum Roller
• Rewinding Arm (both Side)
• Clutch Assembly/mechanically/Magnetic For Rewind Tension
• Counter Balance System
